Lemo Bシリーズ コネクター
Created with Pixso. Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer

Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer

ブランド名: OEM
モデル番号: FGG.2B.312.CLAD
MOQ: 1PC
価格: 交渉可能
配達時間: 3〜10営業日
支払条件: Western Union、MoneyGram、T/T、PayPal
詳細情報
起源の場所:
中国
証明:
CE,ROHS
サイズ:
Lemo 2B
性別:
男性及び女性
絶縁体:
P:PPS
シリーズ:
レモ FGG EGG
交尾サイクル:
5000回
連絡先タイプ:
半田
IP 評価:
IP50
タイプ:
押す引く自動ロック
アプリケーション:
オーディオとビデオ
パッケージの詳細:
PPバッグ
供給の能力:
50000個/月
ハイライト:

LEMO FGG EGG 2B circular connectors

,

LEMO B Series Male Female connectors

,

customized cable assembly LEMO connectors

製品説明
Compatible LEMO FGG EGG 2B Circular Connectors Male And Female With Customized Cable Assembly Manufacturer
Features:
  • Lemo alternative connector
  • FGG EGG 2B 2-12pins male and female connectors
  • Push pull self-locking, very secure systems and easy for mating and unmating
  • Solder type, customized cable assembly welcomed
  • IP Rating:50
  • High-low insulator positioning avoids mismating
  • Good quality with best competitive price, can help you save at least 50% cost
Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 0
Applications:
  1. Camera
  2. Medical
  3. Instrumentation
  4. Industry
  5. Energy
Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 1
Size and Drawing:
Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 2 Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 3 Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 4
Customized Cable Assembly:
  • Get the cable through sleeve collet nut in order, then soldering cable wire to the insulator one by one, please importantly note the wire order
  • Put the split insert carrier to the soldered insulator, to keep the slot of split insert carrier mate perfect with the heave of insulator subassembly
  • Put the collet on the right position of cable, make sure the heave of collet mate with the slot of split insert carrier
  • Push the insulator subassembly split insert carrier collet into the outer shell in order, make sure the heave of split insert carrier mate with the slot of outer shell
  • Screw the collet nut tightly
  • Hitch the sleeve to the corresponding step of collet nut
Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 5 Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 6 Compatible LEMO FGG EGG 2B circular connectors Male And Female With Customized Cable Assmebly Manufacturer 7
